How to replace the exhaust heat shield on a 2.9L engine on Chevrolet Colorado?

First remove the air cleaner outlet duct together with the air cleaner assembly when replacing a 2.9l engine Exhaust Manifold heat shield. According to m30 specifications the transmission filler tube bracket nut needs to be removed from the a.i.r. Adapter until further installation. The heat shield of the Exhaust Manifold needs you to remove first the heated Oxygen Sensor (HO2S) from its position on the Exhaust Manifold after which you detach the three nuts keeping the heat shield on the Exhaust Manifold to finally take off the heat shield. Install the new heat shield to the Exhaust Manifold while using gm p/n 12371386 or canadian p/n 993128 anti-seize on the heat shield nuts. Apply anti-seize gm p/n 12371386 (Canadian P/N 993128) to the heat shield nuts before tightening them to 10 n.m (89 lb in). The procedure requires the ho2s to be reinstalled onto the Exhaust Manifold after the transmission filler tube must be repositioned to the a.i.r. Adapter when this step was conducted. Secure the bracket nut with a torque of 12.5 n.m (111 lb in). Reinstall both the air cleaner assembly followed by the air cleaner outlet duct.

OEM Chevrolet Colorado Exhaust Heat Shield

Heat Shield

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

13 Exhaust Heat Shields found

View related parts
Chevrolet Colorado Heat Shield, Passenger Side Part Number: 12597916
$40.92 MSRP: $60.89
You Save: $19.97 (33%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Shield-Exhaust Manifold Heat; Exhaust Heat Shield; Shield, Exhaust Manifold
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2012 Chevrolet Colorado | LT | 8 Cyl 5.3 L GAS
View related parts
Chevrolet Colorado Heat Shield Part Number: 87865001
$604.97 MSRP: $908.55
You Save: $303.58 (34%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Shield-Spare Wheel Heat
- Replaces: 87865000
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2023-2024 Chevrolet Colorado | LT, Trail Boss, WT, Z71, ZR2 | 2.7L L4, 4 Cyl 2.7 L GAS
View related parts
Chevrolet Colorado Heat Shield Part Number: 86777932
$67.58 MSRP: $100.56
You Save: $32.98 (33%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Shield, Exhaust Tail Pipe
- Position: Rear
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2023 Chevrolet Colorado | LT, Trail Boss, WT, Z71, ZR2 | 4 Cyl 2.7 L GAS
View related parts
Chevrolet Colorado Heat Shield Part Number: 24585435
$27.71 MSRP: $41.24
You Save: $13.53 (33%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Shield, Exhaust Manifold; Exhaust Heat Shield
- Replaced by: 24591081
- Replaces: 24584464
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2016-2022 Chevrolet Colorado | LT, Z71, ZR2 | 4 Cyl 2.8 L DIESEL
View related parts
Chevrolet Colorado Heat Shield Part Number: 22961734
$20.97 MSRP: $31.20
You Save: $10.23 (33%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Shield-Exhaust Interior Underbody Heat; Shield, Exhaust Tail Pipe
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2023 Chevrolet Colorado | LT, Trail Boss, WT, Z71, ZR2 | 4 Cyl 2.7 L GAS
View related parts
Chevrolet Colorado Heat Shield, Driver Side Part Number: 15836245
$4.74 MSRP: $7.06
You Save: $2.32 (33%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Shield, Exhaust Pipe; Exhaust Heat Shield; Shield
- Position: Driver Side
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2012 Chevrolet Colorado | LT | 8 Cyl 5.3 L GAS
View related parts
Chevrolet Colorado Heat Shield Part Number: 12661605
$20.45 MSRP: $30.44
You Save: $9.99 (33%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Shield-Exhaust Manifold Heat; Exhaust Heat Shield; Shield, Exhaust Manifold
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2015-2022 Chevrolet Colorado | Base, LT, WT, Z71 | 4 Cyl 2.5 L GAS
View related parts
Chevrolet Colorado Heat Shield Part Number: 12603060
Product Specifications
- Other Name: Shield-Exhaust Manifold Heat; Exhaust Heat Shield; Shield, Exhaust Manifold
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2004-2006 Chevrolet Colorado | Base, LS, LT, Sport, Sport LS, WT, Z71, Z71 LS, Z85, Z85 LS | 5 Cyl 3.5 L GAS
View related parts
Chevrolet Colorado Heat Shield, Driver Side Part Number: 12598550
Product Specifications
- Other Name: Shield-Exhaust Manifold Heat; Exhaust Heat Shield; Shield, Exhaust Manifold
- Position: Driver Side
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2012 Chevrolet Colorado | LT | 8 Cyl 5.3 L GAS
View related parts
Chevrolet Colorado Heat Shield Part Number: 12578646
Product Specifications
- Other Name: Shield-Exhaust Manifold Heat; Exhaust Heat Shield; Shield, Exhaust Manifold
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007-2012 Chevrolet Colorado | LS, LT, WT | 4 Cyl 2.9 L GAS
View related parts
Chevrolet Colorado Heat Shield Part Number: 12578647
$51.37 MSRP: $76.44
You Save: $25.07 (33%)
Product Specifications
- Other Name: Shield, Exhaust Manifold; Exhaust Heat Shield
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007-2012 Chevrolet Colorado | LS, LT, WT | 5 Cyl 3.7 L GAS
View related parts
Chevrolet Colorado Heat Shield, Passenger Side Part Number: 20873448
Product Specifications
- Other Name: Shield, Catalytic Converter; Exhaust Heat Shield; Front Shield; Shield
- Position: Passenger Side
- Replaces: 25792158, 20907218
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008-2012 Chevrolet Colorado | LS, LT, WT | 4 Cyl 2.9 L GAS, 5 Cyl 3.7 L GAS, 8 Cyl 5.3 L GAS
View related parts
Chevrolet Colorado Heat Shield Part Number: 12593478
Product Specifications
- Other Name: Shield-Exhaust Manifold Heat; Exhaust Heat Shield; Shield, Exhaust Manifold
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2004-2006 Chevrolet Colorado | Base, LS, LT, Sport, Sport LS, WT, Z71, Z71 LS, Z85, Z85 LS | 4 Cyl 2.8 L GAS

Chevrolet Colorado Exhaust Heat Shield

Want to cut long-term maintenance and repair costs? Choose OEM Exhaust Heat Shield. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Chevrolet Colorado parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Chevrolet Colorado Exhaust Heat Shield includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

The Chevrolet Colorado Exhaust Heat Shield is one of the essential parts that indicate the dependability of the Chevrolet Colorado series. Described as a Thermal Energy Control Device for the exhaust system, this Exhaust Heat Shield is important in keeping the exhaust warm in order to let the gases hurry out of it while benefiting the engine, enabling intake air to be cooler and under-hood temperature to be reduced by forty to fifty percent. The Chevrolet Colorado has different categories of Exhaust Heat Shields, such as Exhaust Pipe Heat Shield, Muffler Heat Shield, and other particular sections like Rear and Driver Side for Heat proofing various structures. This versatility shows that Chevrolet Colorado fulfills efficiency and safety requirements as the well-maintained Exhaust Heat Shield is essential to avoid potential misfires that may diminish the vehicle's safety. Utility in different Chevrolet Colorado generations from 2004 up to now guarantees that the drivers need the compatible parking assist feature for different types of truck models to park without being painful in needing assistance, whether in a regular cab, extended, or crew cab trucks. Consequently, the Chevrolet Colorado Exhaust Heat Shield is among the most relevant automotive parts in the market because it is strong as well as has control over heat and safety issues affecting cars. Thus, preserving a proper temperature control, the Chevrolet Colorado Exhaust Heat Shield not only enhances the vehicle lifetime, but also strengthens the Chevrolet brand identity as a producer of reliable and technologically advanced vehicles in the compact to mid-sized pickup segment.

Chevrolet Colorado Exhaust Heat Shield Parts Questions & Experts Answers

Heat Shield
12578647
Q: How to replace the exhaust heat shield on a 2.9L engine on Chevrolet Colorado?
A:
First remove the air cleaner outlet duct together with the air cleaner assembly when replacing a 2.9l engine Exhaust Manifold heat shield. According to m30 specifications the transmission filler tube bracket nut needs to be removed from the a.i.r. Adapter until further installation. The heat shield of the Exhaust Manifold needs you to remove first the heated Oxygen Sensor (HO2S) from its position on the Exhaust Manifold after which you detach the three nuts keeping the heat shield on the Exhaust Manifold to finally take off the heat shield. Install the new heat shield to the Exhaust Manifold while using gm p/n 12371386 or canadian p/n 993128 anti-seize on the heat shield nuts. Apply anti-seize gm p/n 12371386 (Canadian P/N 993128) to the heat shield nuts before tightening them to 10 n.m (89 lb in). The procedure requires the ho2s to be reinstalled onto the Exhaust Manifold after the transmission filler tube must be repositioned to the a.i.r. Adapter when this step was conducted. Secure the bracket nut with a torque of 12.5 n.m (111 lb in). Reinstall both the air cleaner assembly followed by the air cleaner outlet duct.
