How should one safely handle gas charged shock absorbers during maintenance on Chevrolet Silverado 1500 Classic?

The high-pressure gas inside gas charged shock absorbers requires that you maintain the snap ring in its position since removing it produces dangerous eruption of contents that can cause severe injuries. Put on safety glasses when performing shock absorber centerpunching and drilling procedures to avoid both shock absorber tube puncture and personal injury. Use a centerpunch to create an indentation which should be located 10 mm (0.4 inch) from the tube's bottom. A vise should position the shock absorber horizontally while its shock absorber rod extends fully. The 5 mm (3/16 inch) drill bit chisels through the centerpunch while a clamp catches the escaping gas or gas/oil mix; shop towels control the oil discharge. After drilling the first hole through the tube's centerpunch position a second hole needs to be prepared at the same centerpunch point with the identical drill bit for oil release. Protect from leaking oil by using shop towels similar to earlier usage. Complete the oil drain by moving the rod inside the tube through the holes which face downwards while the shock absorber rests above a drain pan.

How to replace a shock absorber on Chevrolet Silverado 1500 Classic?

First step to replace a shock absorber begins with raising the automobile while keeping it secured. The shock absorber replacement process begins by unscrewing and removing the upper shock absorber nut and bolt before moving onto the lower shock absorber nut and bolt until the shock absorber can be extracted. After installation placement must be achieved by positioning the new shock absorber followed by setting it in place with the upper shock absorber nut and bolt. Secure the lower shock absorber by applying the nut and bolt and tighten both nuts to reach 95 Nm (70 ft. lbs.). Finish the procedure by lowering the vehicle after removing safety stands.

OEM Chevrolet Silverado 1500 Classic Shock Absorber

Suspension Shock Absorber

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

10 Shock Absorbers found

View related parts
Chevrolet Silverado 1500 Classic Shock Part Number: 89040416
$76.28 MSRP: $151.50
You Save: $75.22 (50%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Absorber Kit, Front Shock; Suspension Shock Absorber; Shock Absorber; Absorber Kit, Front And Rear Suspension
- Position: Front
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Chevrolet Silverado 1500 Classic | Hybrid | 8 Cyl 5.3 L FULL HYBRID EV-GAS (FHEV)
View related parts
Chevrolet Silverado 1500 Classic Shock Part Number: 89040415
$17.47 MSRP: $116.60
You Save: $99.13 (86%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Absorber Kit, Front Shock; Shock Absorber; Absorber Kit, Front And Rear Suspension
- Position: Front
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Chevrolet Silverado 1500 Classic | Hybrid | 8 Cyl 5.3 L FULL HYBRID EV-GAS (FHEV)
View related parts
Chevrolet Silverado 1500 Classic Shock Part Number: 15935607
$19.16 MSRP: $132.98
You Save: $113.82 (86%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Shock Absorber; Suspension Shock Absorber; Absorber, Front And Rear Suspension
- Position: Rear
- Replaces: 89040417
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Chevrolet Silverado 1500 Classic | Hybrid | 8 Cyl 5.3 L FULL HYBRID EV-GAS (FHEV)
View related parts
Chevrolet Silverado 1500 Classic Shock Absorber Part Number: 89038595
Product Specifications
- Other Name: Absorber Kit, Front Shock; Shock; Absorber Kit, Front And Rear Suspension
- Position: Front
- Replaces: 22064861, 22064859
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Chevrolet Silverado 1500 Classic | Hybrid, LS, LT, SS, WT | 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L FULL HYBRID EV-GAS (FHEV), 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
View related parts
Chevrolet Silverado 1500 Classic Shock Absorber Part Number: 89038596
$168.91 MSRP: $303.00
You Save: $134.09 (45%)
Product Specifications
- Other Name: Absorber Assembly, Rear Shock; Shock; Absorber, Front And Rear Suspension
- Position: Rear
- Replaces: 22064865
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Chevrolet Silverado 1500 Classic | Hybrid, LS, LT, SS, WT | 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L FULL HYBRID EV-GAS (FHEV), 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
View related parts
Chevrolet Silverado 1500 Classic Shock Absorber, Front Part Number: 19168179
$96.73 MSRP: $172.75
You Save: $76.02 (45%)
Product Specifications
- Other Name: Absorber Kit, Front Shock; Shock; Absorber Kit, Front And Rear Suspension
- Position: Front
- Replaces: 12477547, 12477866, 12474681, 15038061, 89040181, 12475345
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Chevrolet Silverado 1500 Classic | LS, LT, SS, WT | 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
View related parts
Chevrolet Silverado 1500 Classic Shock Part Number: 89040418
Product Specifications
- Other Name: Absorber Assembly, Rear Shock; Suspension Shock Absorber; Shock Absorber; Absorber, Front And Rear Suspension
- Position: Rear
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Chevrolet Silverado 1500 Classic | Hybrid | 8 Cyl 5.3 L FULL HYBRID EV-GAS (FHEV)
View related parts
Chevrolet Silverado 1500 Classic Shock Absorber Part Number: 89038597
Product Specifications
- Other Name: Absorber Assembly, Rear Shock; Shock; Absorber, Front And Rear Suspension
- Position: Rear
- Replaces: 22064866
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Chevrolet Silverado 1500 Classic | LS, LT, SS, WT | 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
View related parts
Chevrolet Silverado 1500 Classic Shock Absorber, Front Part Number: 19300057
Product Specifications
- Other Name: Absorber Assembly, Front Shock; Absorber, Front And Rear Suspension
- Position: Front
- Replaces: 22400368, 22400194, 22064848, 88963425
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Chevrolet Silverado 1500 Classic | Hybrid, LS, LT, SS, WT | 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L FULL HYBRID EV-GAS (FHEV), 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
View related parts
Chevrolet Silverado 1500 Classic Shock Absorber, Front Part Number: 19300049
Product Specifications
- Other Name: Absorber Kit, Front Shock; Suspension Shock Absorber; Shock; Absorber Kit, Front And Rear Suspension
- Position: Front
- Replaces: 15048721, 22400192, 88963423, 22400264, 22400818, 22064849, 88967441, 88963424, 88967442
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Chevrolet Silverado 1500 Classic | LS, LT, SS, WT | 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS

Chevrolet Silverado 1500 Classic Shock Absorber

Want to cut long-term maintenance and repair costs? Choose OEM Shock Absorber. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Chevrolet Silverado 1500 Classic parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Chevrolet Silverado 1500 Classic Shock Absorber includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

Chevrolet Silverado 1500 Classic Shock Absorber Parts and Q&A

Shock Absorber
89038596
Q: How should one safely handle gas charged shock absorbers during maintenance on Chevrolet Silverado 1500 Classic?
A:
The high-pressure gas inside gas charged shock absorbers requires that you maintain the snap ring in its position since removing it produces dangerous eruption of contents that can cause severe injuries. Put on safety glasses when performing shock absorber centerpunching and drilling procedures to avoid both shock absorber tube puncture and personal injury. Use a centerpunch to create an indentation which should be located 10 mm (0.4 inch) from the tube's bottom. A vise should position the shock absorber horizontally while its shock absorber rod extends fully. The 5 mm (3/16 inch) drill bit chisels through the centerpunch while a clamp catches the escaping gas or gas/oil mix; shop towels control the oil discharge. After drilling the first hole through the tube's centerpunch position a second hole needs to be prepared at the same centerpunch point with the identical drill bit for oil release. Protect from leaking oil by using shop towels similar to earlier usage. Complete the oil drain by moving the rod inside the tube through the holes which face downwards while the shock absorber rests above a drain pan.
Shock Absorber, Front
19168179
Q: How to replace a shock absorber on Chevrolet Silverado 1500 Classic?
A:
First step to replace a shock absorber begins with raising the automobile while keeping it secured. The shock absorber replacement process begins by unscrewing and removing the upper shock absorber nut and bolt before moving onto the lower shock absorber nut and bolt until the shock absorber can be extracted. After installation placement must be achieved by positioning the new shock absorber followed by setting it in place with the upper shock absorber nut and bolt. Secure the lower shock absorber by applying the nut and bolt and tighten both nuts to reach 95 Nm (70 ft. lbs.). Finish the procedure by lowering the vehicle after removing safety stands.
