How to replace the engine oil cooler hose/pipe for a 6.0L and 8.1L engine on GMC Savana 2500?

The oil cooler features serviceable cooler lines and hoses found within or in front of the radiators separately. Replacements begin with disconnecting all lines attached to the Engine Oil Cooler hose/pipe. Engineers should remove the lower Fan Shroud hose clip on 6.0l vehicles before doing the following procedures: extracting the hoses from the clip followed by slow withdrawal of the pipe fittings from the Radiator's quick connect fittings. Raise the vehicle while applying a support then disconnect engine shield bolts before removing the engine shield. The next step includes removing the oil cooler bracket bolt and bolted adapter nuts of the cooler hose while removing both the hose assembly and retaining gasket which should be discarded. Check every fitting and connector and cooler hose for signs of damage or distortion. An 8.1l engine requires the removal of its Oil Cooler Hose bracket bolt as well as the quick connect fittings at the engine before uninstalling the Oil Cooler Hose assembly while discarding the gasket and performing a damage inspection. Installation requires hearing a distinct snap while connecting tube ends to quick connectors followed by a firm pull to confirm full insertion of the hose assembly. In the installation of the 6.0l engine, install the new gasket after fitting the Oil Cooler Hose assembly followed by applying torque of 12 nm (106 inch lbs.) to loose adapter bolts and 25 nm (18 ft. Lbs.) to the Oil Cooler Hose bracket bolt. Begin by installing engine shields followed by shield bolt tightening to 20 nm (15 ft. Lbs.). When working with a 6.0l vehicle install the oil cooler hoses to the Fan Shroud hose clip before snapping it shut while also checking that the quick connect fitting's end contains a plastic cap. Connect the oil cooler lines. When installing hoses to the clip on an 8.1l engine for the cooler lines until you hear or feel a click against the quick connect fitting then perform a sharp pull-back check.

How to replace the Engine Oil Cooler Hose/Pipe on GMC Sierra 1500?

The oil cooler which can be unitized with Radiator or installed separately in front of the Radiator are serviceable cooler lines and hoses. To replace Engine Oil Cooler hose/pipe, first the remove the plastic caps from the quick connect, pull them back from the pipe. Hold one end of the retaining clip and use a small pick type tool or bent screwdriver to pry the other end free from the quick connect fitting, then rotate and pull the clip off and discard the old clip. For a 6.0l engine, detach from the clip hose for the oil cooler that is located on the lower concealing fan; pull back the hoses but pull the pipe fittings straight out of the q/c fitting in the Radiator. Lift the vehicle, and detach the Exhaust Manifold pipe nuts and relocate the pipe. An 8.1l engine, remove the oil cooler hoses from the clip, and pull the pipe fittings straight out from the Radiator quick connect fittings, then raise and support the vehicle. If equipped, take off the engine shield bolts and the shield. For a 6.0l engine, unscrew the Oil Cooler Hose bracket bolt and the Oil Cooler Hose adapter bolts, sliding off the hoses assembly and replacing the gasket, tossing it aside to inspect the fittings and hoses for damage. In the case of an 8.1l engine, the instructions are as follows: use an allen wrench to remove the bolt for the hose bracket; remove the quick connect fittings at the engine and the hose assembly; discard the gasket and inspect for damage. While installing confirm a snap can be heard when the tube ends of the hose assembly are connected to quick-connectors and the full insertion of the tube can be checked by pulling forcefully. For an 8.1l engine, the quick connect fittings at the engine are connected, the hose bracket bolt is installed, and tightened up to 50 nm (37 ft. Lbs). For a 6.0l engine install hose assembly with a new gasket with tightening adapter bolts to 12 nm (106-inch lbs.), bracket bolt to 25 nm (18 ft. Lbs.). If so provided, mount the engine shield and bolts which you tighten to 20 nm (15 ft. Lbs.) in torque. Place the new retaining clip on the quick connect fitting, making sure that it bites into all the slotted areas: leave this to twist all the way until it locks in place allowing the ears to be visible and the clip to be mobile. Mount a new retaining clip into the other fitting; connect the pipe to the Exhaust Manifold and tighten the nuts to 50 nm (37 ft. Lbs.). Lower the vehicle, then for a 6.0l engines, connect the hoses to the hose clip on the Fan Shroud and push it closed. Put on a plastic cap at the end of the oil cooler line which goes to the quick connect fitting. If damaged or lost, get a new cap prior to installation. For 8.1l, attach the hoses to the clip, connect to the Radiator and pull back sharply to ensure the line enter the fitting until you hear or feel a click. Finally tighten the snap of the plastic cap onto the quick connect fitting ensuring that there is no gap between them.

OEM GMC Oil Cooler Hose

Oil Cooler Line

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

188 Oil Cooler Hoses found

View related parts
GMC Outlet Hose Part Number: 12472265
$75.93 MSRP: $121.59
You Save: $45.66 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Hose Assembly, Engine Oil Cooler Outlet; Oil Cooler Hose; Hose, Engine Oil Cooler
- Replaces: 15657399, 15695822
Fits the following GMC Models:
- C1500 | 1988-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX, Sierra Special | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL
- C2500 | 1988-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L CNG, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- C3500 | 1988-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K1500 | 1988-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX, Sierra Special, Sierra Sport | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL
- K2500 | 1988-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K3500 | 1988-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
View More
View related parts
GMC Inlet Pipe Part Number: 85525392
$68.61 MSRP: $116.81
You Save: $48.20 (42%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe Assembly-Transmission Fluid Cooler; Pipe, Transmission Oil Cooler
- Replaced by: 85630660
Fits the following GMC Models:
- Sierra 2500 HD | 2020-2024 | AT4, AT4X, Base, Denali, Pro, SLE, SLT | 8 Cyl 6.6 L FLEX, 8 Cyl 6.6 L GAS
- Sierra 3500 HD | 2020-2024 | AT4, Base, Denali, Pro, SLE, SLT | 8 Cyl 6.6 L FLEX, 8 Cyl 6.6 L GAS
View related parts
GMC Inlet Hose Part Number: 15748403
$65.34 MSRP: $103.74
You Save: $38.40 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Hose, Transmission Oil Cooler
- Replaces: 15996165
Fits the following GMC Models:
- C2500 | 1996 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 7.4 L GAS
- C3500 | 1996 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 7.4 L GAS
- K2500 | 1996 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 7.4 L GAS
- K3500 | 1996 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 7.4 L GAS
View More
View related parts
GMC Cooler Pipe Part Number: 85532819
$99.52 MSRP: $170.90
You Save: $71.38 (42%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe, Transmission Oil Cooler; Line
- Replaced by: 86584017
Fits the following GMC Models:
- Sierra 1500 | 2019-2023 | AT4, AT4X, Denali, Denali Ultimate, SLT | 8 Cyl 6.2 L GAS
View related parts
GMC Inlet Hose Part Number: 12472290
$36.53 MSRP: $88.05
You Save: $51.52 (59%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Hose, Engine Oil Cooler; Oil Cooler Hose
- Replaces: 15696690, 15695859
Fits the following GMC Models:
- C1500 | 1992-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX, Sierra Special | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL
- C2500 | 1992-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L CNG, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- C3500 | 1992-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K1500 | 1992-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX, Sierra Special, Sierra Sport | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL
- K2500 | 1992-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K3500 | 1992-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
View More
View related parts
GMC Inlet Hose Part Number: 12472268
$32.48 MSRP: $65.24
You Save: $32.76 (51%)
ADD TO CART
Product Specifications
- Other Name: Hose, Engine Oil Cooler Inlet; Oil Cooler Hose; Oil Cooler Pipe; Hose, Engine Oil Cooler
- Replaces: 15659428
Fits the following GMC Models:
- C1500 | 1992-1993 | Sierra, Sierra SLE, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL
- C2500 | 1991-1993 | Sierra, Sierra SLE, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L CNG, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- C2500 Suburban | 1992-1993 | Base, SLE | 8 Cyl 7.4 L GAS
- C3500 | 1991-1993 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K1500 | 1992-1993 | Sierra, Sierra SLE, Sierra SLX, Sierra Sport | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL
- K2500 | 1991-1993 | Sierra, Sierra SLE, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K2500 Suburban | 1992-1993 | Base, SLE | 8 Cyl 7.4 L GAS
- K3500 | 1991-1993 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
View More
View related parts
GMC Outlet Pipe Part Number: 12725092
$37.00 MSRP: $66.08
You Save: $29.08 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe, Engine Coolant; Cooler Pipe; Pipe, Engine Oil Cooler
- Replaces: 12636733, 97188664, 97328878
Fits the following GMC Models:
- Savana 2500 | 2010-2016 | Base | 8 Cyl 6.6 L DIESEL
- Savana 3500 | 2010-2016 | Base, LS, LT | 8 Cyl 6.6 L DIESEL
- Sierra 2500 HD | 2017-2024 | AT4, AT4X, Base, Denali, Denali Ultimate, Pro, SLE, SLT | 8 Cyl 6.6 L DIESEL
- Sierra 3500 HD | 2017-2024 | AT4, Base, Denali, Denali Ultimate, Pro, SLE, SLT | 8 Cyl 6.6 L DIESEL
View More
View related parts
GMC Cooler Pipe Part Number: 86818095
$181.97 MSRP: $315.67
You Save: $133.70 (43%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe, Transmission Oil Cooler; Line
- Replaces: 84651358, 84527053, 84846539, 84620868, 84885688, 84889805, 85532817
Fits the following GMC Models:
- Sierra 1500 | 2020-2023 | AT4, AT4X, Denali, Denali Ultimate, Elevation, SLE, SLT | 6 Cyl 3.0 L DIESEL
- Sierra 1500 Limited | 2022 | AT4, Denali, Elevation, SLE, SLT | 6 Cyl 3.0 L DIESEL
View related parts
GMC Outlet Pipe Part Number: 84348114
$89.79 MSRP: $216.49
You Save: $126.70 (59%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pipe, Transmission Oil Cooler
- Replaces: 84042575
Fits the following GMC Models:
- Sierra 2500 HD | 2017-2019 | Base, Denali, SLE, SLT | 8 Cyl 6.6 L DIESEL
- Sierra 3500 HD | 2017-2019 | Base, Denali, SLE, SLT | 8 Cyl 6.6 L DIESEL
View related parts
GMC Cooler Pipe Part Number: 85563686
$135.66 MSRP: $213.42
You Save: $77.76 (37%)
Product Specifications
- Other Name: Pipe, Transmission Oil Cooler; Line
- Replaces: 84527055, 85149480, 84885689, 84651356, 85532815
Fits the following GMC Models:
- Sierra 1500 | 2019-2021 | AT4, Base, Denali, Elevation, SLE, SLT | 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS
View related parts
GMC Outlet Pipe Part Number: 15982923
Product Specifications
- Other Name: Hose Assembly-Transmission Oil Auxiliary Cooler Outlet; Transmission Oil Cooler Line; Outlet Hose; Hose, Transmission Oil Cooler; Pipe, Transmission Oil Cooler
- Replaces: 15982925
Fits the following GMC Models:
- C1500 | 1993-1995 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX, Sierra Special | 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS
- C2500 | 1993-1995 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L CNG, 8 Cyl 5.7 L GAS
- C3500 | 1993-1995 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.7 L GAS
- K1500 | 1993-1995 | Sierra, Sierra SL, Sierra SLE, Sierra SLS, Sierra SLT, Sierra SLX, Sierra Special, Sierra Sport | 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS
- K2500 | 1993-1995 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS
- K3500 | 1993-1995 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.7 L GAS
View More
View related parts
GMC Outlet Pipe Part Number: 15983143
Product Specifications
- Other Name: Hose Assembly-Transmission Oil Auxiliary Cooler Outlet; Pipe, Transmission Oil Cooler
Fits the following GMC Models:
- C1500 | 1995 | Sierra SL, Sierra SLE, Sierra SLT, Sierra Special | 8 Cyl 6.5 L DIESEL
- C2500 | 1995 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 6.5 L DIESEL
- C3500 | 1995 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 6.5 L DIESEL
- K1500 | 1995 | Sierra SL, Sierra SLE, Sierra SLS, Sierra SLT, Sierra Special | 8 Cyl 6.5 L DIESEL
- K2500 | 1995 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 6.5 L DIESEL
- K3500 | 1995 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 6.5 L DIESEL
View More
View related parts
GMC Outlet Pipe Part Number: 15980548
Product Specifications
- Other Name: Hose, Transmission Oil Cooler; Transmission Oil Cooler Line; Outlet Hose; Pipe, Transmission Oil Cooler
Fits the following GMC Models:
- C1500 | 1993-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX, Sierra Special | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL
- C2500 | 1993-1995 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L CNG, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- C3500 | 1993-1995 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K1500 | 1993-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX, Sierra Special, Sierra Sport | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL
- K2500 | 1993-1995 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K3500 | 1993-1995 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
View More
View related parts
GMC Inlet Hose Part Number: 12472263
Product Specifications
- Other Name: Hose, Engine Oil Cooler; Oil Cooler Hose
- Replaces: 15657397
Fits the following GMC Models:
- C1500 | 1988-1991 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 6.2 L DIESEL
- C2500 | 1988-1991 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 6.2 L DIESEL
- C3500 | 1988-1991 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 6.2 L DIESEL
- K1500 | 1988-1991 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 6.2 L DIESEL
- K2500 | 1988-1991 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 6.2 L DIESEL
- K3500 | 1988-1991 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 6.2 L DIESEL
View More
View related parts
GMC Outlet Hose Part Number: 12472269
Product Specifications
- Other Name: Hose, Engine Oil Cooler; Oil Cooler Hose; Oil Cooler Pipe
- Replaces: 15659429
Fits the following GMC Models:
- C1500 | 1992-1993 | Sierra, Sierra SLE, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL
- C2500 | 1991-1993 | Sierra, Sierra SLE, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L CNG, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- C2500 Suburban | 1992-1993 | Base, SLE | 8 Cyl 7.4 L GAS
- C3500 | 1991-1993 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K1500 | 1992-1993 | Sierra, Sierra SLE, Sierra SLX, Sierra Sport | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL
- K2500 | 1991-1993 | Sierra, Sierra SLE, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K2500 Suburban | 1992-1993 | Base, SLE | 8 Cyl 7.4 L GAS
- K3500 | 1991-1993 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
View More
View related parts
GMC Outlet Hose Part Number: 15980549
Product Specifications
- Other Name: Hose, Transmission Oil Cooler; Transmission Oil Cooler Line; Pipe, Transmission Oil Cooler
Fits the following GMC Models:
- C1500 | 1993-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX, Sierra Special | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL
- C2500 | 1993-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L CNG, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- C3500 | 1993-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K1500 | 1993-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX, Sierra Special, Sierra Sport | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL
- K2500 | 1993-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K3500 | 1993-1994 | Sierra, Sierra SL, Sierra SLE, Sierra SLT, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
View More
View related parts
GMC Oil Cooler Pipe Part Number: 12472287
Product Specifications
- Other Name: Hose, Engine Oil Cooler
- Replaces: 15695839
Fits the following GMC Models:
- C2500 Suburban | 1993 | Base, SLE | 8 Cyl 7.4 L GAS
- K2500 Suburban | 1993 | Base, SLE | 8 Cyl 7.4 L GAS
View related parts
GMC Oil Cooler Pipe Part Number: 12472288
Product Specifications
- Other Name: Hose Assembly, Engine Oil Cooler Outlet; Hose, Engine Oil Cooler
- Replaces: 15695840
Fits the following GMC Models:
- C2500 Suburban | 1993 | Base, SLE | 8 Cyl 7.4 L GAS
- K2500 Suburban | 1993 | Base, SLE | 8 Cyl 7.4 L GAS
View related parts
GMC Outlet Hose Part Number: 12472264
Product Specifications
- Other Name: Hose Assembly, Engine Oil Cooler Outlet; Oil Cooler Hose; Hose, Engine Oil Cooler
Fits the following GMC Models:
- C1500 | 1992-1993 | Sierra, Sierra SLE, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL
- C2500 | 1992-1993 | Sierra, Sierra SLE, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L CNG, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- C3500 | 1992-1993 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K1500 | 1992-1993 | Sierra, Sierra SLE, Sierra SLX, Sierra Sport | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL
- K2500 | 1992-1993 | Sierra, Sierra SLE, Sierra SLX | 6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
- K3500 | 1992-1993 | Sierra, Sierra SLE, Sierra SLX | 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
View More
View related parts
GMC Inlet Hose Part Number: 15127520
Product Specifications
- Other Name: Hose Assembly-Engine Oil Cooler Inlet; Oil Cooler Hose; Oil Cooler Pipe; Hose, Engine Oil Cooler
- Replaces: 15985753
Fits the following GMC Models:
- C2500 | 1997-2000 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 7.4 L GAS
- C2500 Suburban | 1996 | Base, SLE, SLT | 8 Cyl 7.4 L GAS
- C3500 | 1997-2000 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 7.4 L GAS
- K2500 | 1997-2000 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 7.4 L GAS
- K2500 Suburban | 1996 | Base, SLE, SLT | 8 Cyl 7.4 L GAS
- K3500 | 1997-2000 | Sierra SL, Sierra SLE, Sierra SLT | 8 Cyl 7.4 L GAS
View More

| Page 1 of 10 |Next >

1-20 of 188 Results

GMC Oil Cooler Hose

Choose OEM Oil Cooler Hose, you're making the optimal decision for superior quality and perfect performance. You can feel confident because each component goes through stringent quality checks. Every part is carefully built to comply with GMC's factory specifications. You'll enjoy a smooth, worry-free installation that fits just right. At ChevyPartsGiant.com, you'll find it easy to get top-quality OEM GMC Oil Cooler Hose. You can shop at highly competitive prices and protect your budget. All our genuine GMC parts include a dependable manufacturer's warranty. You'll also appreciate our straightforward return policy and swift delivery services for extra convenience.

GMC Oil Cooler Hose Parts and Q&A

Inlet Pipe
15808251
Q: How to replace the engine oil cooler hose/pipe for a 6.0L and 8.1L engine on GMC Savana 2500?
A:
The oil cooler features serviceable cooler lines and hoses found within or in front of the radiators separately. Replacements begin with disconnecting all lines attached to the Engine Oil Cooler hose/pipe. Engineers should remove the lower Fan Shroud hose clip on 6.0l vehicles before doing the following procedures: extracting the hoses from the clip followed by slow withdrawal of the pipe fittings from the Radiator's quick connect fittings. Raise the vehicle while applying a support then disconnect engine shield bolts before removing the engine shield. The next step includes removing the oil cooler bracket bolt and bolted adapter nuts of the cooler hose while removing both the hose assembly and retaining gasket which should be discarded. Check every fitting and connector and cooler hose for signs of damage or distortion. An 8.1l engine requires the removal of its Oil Cooler Hose bracket bolt as well as the quick connect fittings at the engine before uninstalling the Oil Cooler Hose assembly while discarding the gasket and performing a damage inspection. Installation requires hearing a distinct snap while connecting tube ends to quick connectors followed by a firm pull to confirm full insertion of the hose assembly. In the installation of the 6.0l engine, install the new gasket after fitting the Oil Cooler Hose assembly followed by applying torque of 12 nm (106 inch lbs.) to loose adapter bolts and 25 nm (18 ft. Lbs.) to the Oil Cooler Hose bracket bolt. Begin by installing engine shields followed by shield bolt tightening to 20 nm (15 ft. Lbs.). When working with a 6.0l vehicle install the oil cooler hoses to the Fan Shroud hose clip before snapping it shut while also checking that the quick connect fitting's end contains a plastic cap. Connect the oil cooler lines. When installing hoses to the clip on an 8.1l engine for the cooler lines until you hear or feel a click against the quick connect fitting then perform a sharp pull-back check.
Outlet Pipe, Lower
15773661
Q: How to replace the Engine Oil Cooler Hose/Pipe on GMC Sierra 1500?
A:
The oil cooler which can be unitized with Radiator or installed separately in front of the Radiator are serviceable cooler lines and hoses. To replace Engine Oil Cooler hose/pipe, first the remove the plastic caps from the quick connect, pull them back from the pipe. Hold one end of the retaining clip and use a small pick type tool or bent screwdriver to pry the other end free from the quick connect fitting, then rotate and pull the clip off and discard the old clip. For a 6.0l engine, detach from the clip hose for the oil cooler that is located on the lower concealing fan; pull back the hoses but pull the pipe fittings straight out of the q/c fitting in the Radiator. Lift the vehicle, and detach the Exhaust Manifold pipe nuts and relocate the pipe. An 8.1l engine, remove the oil cooler hoses from the clip, and pull the pipe fittings straight out from the Radiator quick connect fittings, then raise and support the vehicle. If equipped, take off the engine shield bolts and the shield. For a 6.0l engine, unscrew the Oil Cooler Hose bracket bolt and the Oil Cooler Hose adapter bolts, sliding off the hoses assembly and replacing the gasket, tossing it aside to inspect the fittings and hoses for damage. In the case of an 8.1l engine, the instructions are as follows: use an allen wrench to remove the bolt for the hose bracket; remove the quick connect fittings at the engine and the hose assembly; discard the gasket and inspect for damage. While installing confirm a snap can be heard when the tube ends of the hose assembly are connected to quick-connectors and the full insertion of the tube can be checked by pulling forcefully. For an 8.1l engine, the quick connect fittings at the engine are connected, the hose bracket bolt is installed, and tightened up to 50 nm (37 ft. Lbs). For a 6.0l engine install hose assembly with a new gasket with tightening adapter bolts to 12 nm (106-inch lbs.), bracket bolt to 25 nm (18 ft. Lbs.). If so provided, mount the engine shield and bolts which you tighten to 20 nm (15 ft. Lbs.) in torque. Place the new retaining clip on the quick connect fitting, making sure that it bites into all the slotted areas: leave this to twist all the way until it locks in place allowing the ears to be visible and the clip to be mobile. Mount a new retaining clip into the other fitting; connect the pipe to the Exhaust Manifold and tighten the nuts to 50 nm (37 ft. Lbs.). Lower the vehicle, then for a 6.0l engines, connect the hoses to the hose clip on the Fan Shroud and push it closed. Put on a plastic cap at the end of the oil cooler line which goes to the quick connect fitting. If damaged or lost, get a new cap prior to installation. For 8.1l, attach the hoses to the clip, connect to the Radiator and pull back sharply to ensure the line enter the fitting until you hear or feel a click. Finally tighten the snap of the plastic cap onto the quick connect fitting ensuring that there is no gap between them.
