1993 Chevrolet G20 A/C Condenser, Compressor & Lines

Currently shopping for

1993 Chevrolet G20

Change Vehicle

Categories Close X

Currently selected

A/C & Heating

Other Categories

Air & Fuel Delivery

Belts & Cooling

Body & Hardware

Brakes

Charging & Starting

Driveline & Axles

Electrical

Emission Control & Exhaust

Engine

Headlights & Lighting

Interior & Exterior Trim

Maintenance & Lubrication

Steering

Suspension

Transmission

Parts Questions

Diagram (1 of 1): Air Conditioner & Heater - Compressor & Lines Condenser

1993 Chevy G20 A/C Condenser, Compressor & Lines Diagram

Enlarge Diagram

Sort by:

Ref No.

Ref No.

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

1
52494069
Condenser
- Part Notes: All W/O 7.4 Liter

2
2724885
Dehydrator
- Part Notes: Diesel;Gas

3
1131571
Compressor
Part Notes: Axial 8 Cylinder Gas, Diesel
3
1136502
Compressor
- Part Notes: Radial
3
2724150
Compressor
- Part Notes: Axial 6 Cylinder;Axial 8 Cylinder Gas, 5.0 & 5.7 Liter, Fuel Injection

4
15562567
Hose
Part Notes: Compressor, 8 Cylinder, Diesel
4
15572484
Hose
- Part Notes: Compressor, 8 Cylinder, Gas
4
15572486
Hose
- Part Notes: Compressor, 6 Cylinder, W/4.3 Liter

6
15562577
Tube
Part Notes: Evaporator
6
15562581
Tube
- Part Notes: Auxiliary Evaporator

7
52458776
Evaporator Core
Part Notes: Roof Mounted
7
52459628
Evaporator Core
- Part Notes: Floor Mounted, All;Floor Mounted, Diesel
7
3012076
Evaporator Core Seal
- Part Notes: Roof Mounted, Lower
7
3012077
Evaporator Core Seal
- Part Notes: Roof Mounted, Upper

8
52463362
Case
- Part Notes: Standard, Inlet

9
3054952
Case
- Part Notes: Standard, Outlet

10
88959521
Blower Motor
Part Notes: Floor Mounted
$179.30 $100.41
1
Add To Cart
10
19179470
Blower Motor
- Part Notes: Roof Mounted

11
52460704
Fan
$68.12 $38.15
1
Add To Cart

3025867
Case
Part Notes: Roof Mounted, Lower
3025868
Case
- Part Notes: Roof Mounted, Upper

3091128
Clutch Coil
Part Notes: All Models; 4.3l;All Models; 5.0l, 5.7l
6550835
Clutch Coil
- Part Notes: All Models; 6.2l Diesel;Axial Compressor, Diesel

5914719
Clutch Plate & Hub Assembly
Part Notes: All Models; 6.2l Diesel
89019049
Clutch Plate & Hub Assembly
- Part Notes: All Models; 4.3l, 5.0l, 5.7l, 7.4l
$259.66 $144.76
1
Add To Cart

12300271
Compressor
- Part Notes: All Models; 6.2l Diesel

10069966
Compressor Mount Bracket

14050561
Compressor Support
- Part Notes: Diesel

15530486
Dehydrator Clamp

52450069
Evaporator Core Seal
- Part Notes: Floor Mounted

10129560
Idler Pulley
- Part Notes: W/Fuel Injection
$81.34 $45.55

10179211
Idler Pulley Bracket

6580037
Pulley
Part Notes: All Models; 4.3l, 5.0l, 5.7l, 7.4l
6550750
Pulley
- Part Notes: All Models; 6.2l Diesel;Axial

2724959
Shaft Seals
Part Notes: All Models; 4.3l, 5.0l, 5.7l, 7.4l
6591956
Shaft Seals
- Part Notes: All Models; 6.2l Diesel

15674325
FITTING,A/C COMPRESSOR TUBE(.75" O.D.)
- Fitting Vehicle Options: G1,2,3(YF7)(EXC C69)
$93.93 $52.60
View Details

5858696
GASKET,A/C COMPRESSOR OIL DRAIN PLUG(ALSO PART OF ITEM #12)
- Fitting Vehicle Options: G2,3(LH6), G2,3(LL4)

6590589
NUT,A/C COMPRESSOR(KIT, 1 FLANGE TYPE NUT, 4 REGULAR NUTS)
- Fitting Vehicle Options: G2,3(LH6,C60)

9440355
BOLT,HEX FLANGED HEAD 3/8-16X3.50 280M PHOSPHATE ORGANIC 1.12 THREAD.75-OUTSIDE DIAMETER(GENERATOR & DRIVE BELT IDLER PULLEY BRACKET)

11513606
BOLT, M10X1.5X35(8.900)
$4.26 $2.69
View Details

9424069
BOLT,HEXAGON 7/16-14UNC-2AX1.25,1.07 THREAD,GM300M,PC,MACHINE
- Fitting Vehicle Options: 1,2,3
$5.42 $3.46
View Details

9440169
BOLT,HEX FLANGED HEAD 3/8-16X.88 280M PHOSPHATE ORGANIC 6174M
$7.20 $4.59
View Details

15969560
SEAL,HEATER(CORE)
- Fitting Vehicle Options: G1,2,3

15674324
FITTING,A/C EVAPORATOR TUBE
- Fitting Vehicle Options: G1,2,3(YF7)(EXC C69)

9439513
WASHER,HELICAL SPRING LOCK 29/64 X 49/64 X 7/64
$3.46 $2.21
View Details

3041240
BRACKET,TEMPERATURE CONTROL CABLE
- Fitting Vehicle Options: G1,2,3(C60)

15973052
RESISTOR,AUXILIARY A/C BLOWER MOTOR
- Fitting Vehicle Options: G1,2,3(C69)

89019177
NUT,A/C CLUTCH
- Fitting Vehicle Options: G1,2,3
$13.18 $7.38
View Details

3037399
INLET,AIR(INLET ONLY)(9.211)
- Fitting Vehicle Options: G1,2,3(C60)

3037508
HOUSING,TEMPERATURE VALVE(INCLUDES 32)
- Fitting Vehicle Options: G1,2,3(C60)
