Diagram (1 of 1): Rear Suspension - Brake Components

2001 Chevy Express 3500 Rear Brakes Diagram

Enlarge Diagram

Sort by:

Ref No.

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

1
15635951
Brake Drum
- Part Notes: 1 Ton
- Location: Driver Side;Passenger Side

2
15650041
Hub
- Location: Driver Side;Passenger Side

3
12471641
Hub Gasket
- Location: Driver Side;Passenger Side
$17.50 $11.17
1
Add To Cart

4
15622344
Backing Plate
Part Notes: 3/4 & 1 Ton, W/13x3.5" Brake
Location: Passenger Side
4
15622343
Backing Plate
- Part Notes: 3/4 & 1 Ton, W/13x3.5" Brake
- Location: Driver Side

5
18029766
Wheel Cylinder
- Location: Driver Side;Passenger Side

19366771
Brake Hose
- Part Notes: Express, Savana
- Location: Driver Side;Passenger Side

15693468
Drum
- Part Notes: Express, Savana; 1 Ton; W/O Dual Rear Wheels

19213344
Wheel Cylinder
- Part Notes: Express, Savana; 1 Ton
$131.40 $73.58
1
Add To Cart

5466564
Wheel Cylinder Overhaul Kit
- Part Notes: Express, Savana; 3/4, 1 Ton

9439511
WASHER,HELICAL SPRING LOCK,21/64 INSIDE DIAMETER,37/64 O.D.,5/64 THICK,ZO
$2.31 $1.47
View Details

15522078
ADJUSTER,REAR BRAKE SHOE(USE TOGETHER WITH 15522080 NUT)(*KIT2)
- Location: Passenger Side
- Fitting Vehicle Options: G3(JB8)

15758798
FITTING,INVERTER FLD TUBE 7/16-24 UNS BRASS(REAR BRAKE PIPE)
- Fitting Vehicle Options: (NL1)
$26.98 $15.11
View Details

15250738
CLIP,REAR BRAKE PIPE(HOLDS 4 PIPES/HOSES)(3.162)
- Fitting Vehicle Options: G3(03-32)(NL1)
$5.03 $3.21
View Details

18003901
COVER,REAR BRAKE BLEEDER BOLT(MOUNTED TO CALIPER)(BLACK)(3/8-24 THREAD)(RUBBER)(FOR REPAIR USE ONLY)
- Fitting Vehicle Options: G1,2,3

15724652
NUT,TUBE 7/16-24X0.36,0.30THD,0.56 LONG,1/4 TUBE,STEEL,ZINC COATED CO GM6280M(REAR BRAKE REAR PIPE)
- Fitting Vehicle Options: (NL1)
$8.00 $4.48
View Details

15103241
NUT,REAR BRAKE PIPE(1/2-20 -2A THREAD)(1/4 TUBE STEEL)
- Fitting Vehicle Options: G1,2,3
$13.76 $7.71
View Details

3856855
PIVOT,REAR BRAKE SHOE ADJUSTER ACTUATOR(ALSO PART OF ITEM #12)
- Location: Driver Side
- Fitting Vehicle Options: G1,2,3

15649277
WASHER,REAR BRAKE ANCHOR PINION
- Fitting Vehicle Options: G2,3

12547207
TUBING,BULK, 3/16" X 20 FT ROLL,STEEL(FRONT BRAKE)(8.964)
- Location: Passenger Side
$48.46 $27.14
View Details

15749353
CLIP,REAR AXLE VENT HOSE("NYLON" 8.5MM CLA INSIDE DIAMETER - W/TREE RETAINER & LOCATING PINION)
- Fitting Vehicle Options: G1,2,3
$10.36 $6.61
View Details

9422308
NUT, 3/4 -16(REAR BRAKE ANCHOR PINION)
- Require Quantity: 02
- Package Quantity: 1
$8.16 $5.21
View Details

15634818
SPRING KIT,REAR BRAKE SHOE ADJUSTER & RETURN(INCLUDE SPRING)(13 X 2.5, 13 X 3.5, 11.15 X 2.75 BRAKES)(INCLUDE ITEMS #10,11,14,15,18,24)
- Fitting Vehicle Options: G3(JB8)
$39.85 $22.31
View Details

11588802
NUT,HEXAGON,3/8-24X9/16,12.0 O.D.,LOW CARBURETOR STEEL(FRONT BRAKE PIPE)
- Require Quantity: 02
- Package Quantity: 1
$13.79 $8.80
View Details

357845
ACTUATOR,REAR BRAKE SHOE ADJUSTER(W/13 X 2.50 & 13 X 3.50 BRAKES)(INCLUDE ITEMS #11,19)
- Location: Driver Side
- Fitting Vehicle Options: G3(JB8)

88959957
RING,REAR PARKING BRAKE LEVER RETAINER(REAR PARKING BRAKE LEVER RETAINER)
- Require Quantity: 02
- Package Quantity: 1
$4.00 $2.56
