Diagram (1 of 1): Fuel System Components

2003 Hummer H2 Fuel System Components Diagram

Enlarge Diagram

Sort by:

Ref No.

Ref No.

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

1
15203679
Fuel Tank

2
25884456
Shield

3
15795683
Strap
- Location: Passenger Side
3
15795684
Strap
- Location: Driver Side
$16.52 $11.10
1
Add To Cart

4

15064311
Cap
$59.31 $33.21
1
Add To Cart

5
15191438
Filler Pipe

6

15903412
Fuel Pocket

7
19369916
Module
$481.85 $268.64
1
Add To Cart

10
25358783
Level Sensor

15724226
STUD,FUEL TANK STRAP(HEX FLANGED HEAD,M8X1.25X20,M10X1.5X35,18 OUTSIDE DIAMETER,64.5 TL,9.8,7114M)(4.047)
- Fitting Vehicle Options: N2
- Require Quantity: 02
- Package Quantity: 1
$8.52 $5.44
View Details

11516885
SCREW,HEX FLANGED HEAD W/FLAT WASHER,TAP,M8X1.25X20,7THD,17 O.D.,TRIM POINT,6202M,PHOSPHATE ZINC ORGANIC(FUEL TANK FILLER & VENT HOSE BRACKET)
$7.38 $4.72
View Details

11609754
CLAMP,WORM GEAR,SIZE 36, 64.26 MIN DIAMETER 51.56 MAX DIAMETER, STAINLESS STEEL.(PART OF 17)
- Replaced By: 12338017
$8.41 $5.64
View Details

11517792
NUT,HEXAGON W/FLAT WASHER,M8X1.25,10.75 THICK,24 OUTSIDE DIAMETER,10,7111M(FUEL TANK SHIELD)
- Require Quantity: 02
- Package Quantity: 1
$6.00 $3.83
View Details
