2008 Saturn Vue Transaxle Parts
Currently shopping for
2008 Saturn Vue
Change VehicleCategories Close X
Currently selected
Engine
Other Categories
A/C & Heating
Air & Fuel Delivery
Belts & Cooling
Body & Hardware
Brakes
Charging & Starting
Driveline & Axles
Electrical
Emission Control & Exhaust
Headlights & Lighting
Interior & Exterior Trim
Maintenance & Lubrication
Steering
Suspension
Transmission
Parts Questions
4 diagrams found for the vehicle you selected.Select your vehicle options to narrow down results.
- 1.Engine - Transaxle (2.4L)
- 2.Engine - Transaxle (2.4L), (Electric/Gas), (Green Line)
- 3.Engine - Transaxle (3.5L)
- 4.Engine - Transaxle (3.6L)
Sort by:
Ref No.
Ref No.
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
Part Description
- 1
- 1
$64.20 $43.141
- 2
$9.75 $6.201
- 2
- 3
- 3
- 4
- 4
$7.40 $4.721
$92.24 $58.88
24240315
BEARING,FRONT DIFFERENTIAL CARRIER THRUST(57.3MM O.D. X 36.5MM INSIDE DIAMETER)- Fitting Vehicle Options: L(LE5,LE9,MN5,FX2), L(LAT,ME7,FY1)
$11.71 $7.47
24240101
BODY KIT,CONTROL VALVE(INCLUDES GASKET,PLATES,SEALS & RETAINER)(LESS BODY)(PI# 0380 APPLIES TO THIS PART NUMBER. PER GM SERVICE POLICIES & PROC EDURES, FAILURE TO FOLLOW THE PI MAY RESULT IN THE REJECTION OF A WARRANTY CLAIM)- Fitting Vehicle Options: L(MH2,MH4)
- Replaced By: 24262197
$315.03 $200.22
24245564
PIN,CONTROL VALVE BODY LOCATING(VALVE BODY)- Fitting Vehicle Options: L(MH2,MH4)
- Require Quantity: 04
- Package Quantity: 1
$3.80 $2.36
24242439
CARRIER,INPUT(W/REACTION INTERNAL GEAR)(SEE GROUP 04.000 "INPUT CARRIER" FOR DETAILED ILLUSTRATED VIEW)- Fitting Vehicle Options: L(LE5,MN5,FX2), L(LAT,ME7,FY1)
- 19260611
HOUSING,DIRECT & COAST CLUTCH(SEE GROUP 04.000 "DIRECT & COAST CLUTCH" FOR DETAILED ILLUSTRATED VIEW)- Fitting Vehicle Options: L(MN5), L(ME7)
$617.14 $392.41
24200790
PLATE,2ND CLUTCH(STEEL)- Fitting Vehicle Options: L(MN5), L(ME7)
- Require Quantity: 03
- Package Quantity: 1
24213704
SEAL,AUTOMATIC TRANSMISSION WIRING CONNECT (O RING)(2.559)- Fitting Vehicle Options: LF(LE5,MN5,FX2)
$7.39 $4.72
24207861
BOLT,VALVE BODY(M6X1X65)(10MM HEAD)- Fitting Vehicle Options: L(MH2,MH4)
- Require Quantity: 08
- Package Quantity: 1
$15.72 $10.04
24217840
DAM,FRONT DIFFERENTIAL DRIVE PINION GEAR LUBRICANT- Fitting Vehicle Options: L(MH2,MH4,D70), LR(LY7,MH2,D70), LR(26)(LY7,MH4,D70,V9H)
$7.22 $4.59
8680884
BOLT,AUTOMATIC TRANSMISSION FLUID TROUGH(M6X1.0X31)(4.228)- Fitting Vehicle Options: L(MH2,MH4)
$5.46 $3.48
24245914
PLATE,CONTROL VALVE BODY SPACER(INCLUDE GASKETS)(TRANS BUILT ON 01-23-08 & AFTER)(FOR 1ST DESIGN SEE 24235005)- Fitting Vehicle Options: L(MN5)(SERV BULLETIN# 08-07-30-034 APPLIES TO THIS PART #.PER GM SERV POLICIES & PROC,FAILURE TO FOLLOW THE BULLETIN MAY RES IN THE REJ OF A WARR CLAIM)(2ND DES)
$18.45 $11.78
$9.54 $6.10
$39.37 $25.13
$9.19 $5.87
22674165
RING,FRONT WHEEL DRIVE SHAFT RETAINER(DRIVE SHAFT)(OUTSIDE DIAMETER IS 27.5MM BARREL DESIGN)(*KIT2,KIT3)- Fitting Vehicle Options: L(LE5), L(LAT)
- Require Quantity: 02
- Package Quantity: 1
$18.46 $11.78
- 24201096
GASKET,AUTOMATIC TRANSMISSION CASE COVER(PART OF 27)(*KIT1,KIT2)- Fitting Vehicle Options: L(MN5)
$66.49 $42.45
24211329
CONVERTER,TORQUE(REMANUFACTURED-NOT FOR SALE WHERE IMPORTS ARE RESTRICTED)- Fitting Vehicle Options: L(LE5,LE9,MN5)
- Require Quantity: 02
- Package Quantity: 1
$7.42 $4.72
24044493
COVER,AUTOMATIC TRANSMISSION VENT PROTECTIVE(4.133)- Fitting Vehicle Options: LF,LR(LE5,MN5,FX2)
$11.38 $7.28
$50.92 $32.50
24229665
HARNESS,AUTOMATIC TRANSMISSION WIRING(MATING CONNECT USE 89046897 20-WAY W/O LEADS)(2.480)- Fitting Vehicle Options: LF(LE5)
$366.06 $204.08
24245360
PLATE,DIRECT CLUTCH(INCLUDES 90)(FIBER)(TRANS BUILT ON 01-07-08 & AFTER)(FOR 1ST DESIGN SEE 24247457)- Fitting Vehicle Options: L(ME7)(SERV BULLETIN# 08-07-30-034 APPLIES TO THIS PART #.PER GM SERV POLICIES & PROC,FAILURE TO FOLLOW THE BULLETIN MAY RES IN THE REJ OF A WARR CLAIM)(2ND DES)
- Require Quantity: 06
- Package Quantity: 1
$5.88 $3.77
$184.07 $116.99
$21.62 $13.80
$27.44 $17.53
24203911
BOLT,AUTOMATIC TRANSMISSION FLUID PAN(M6X1X19,9.8)- Fitting Vehicle Options: L(MN5)
- Require Quantity: 12
- Package Quantity: 1
$13.54 $8.60
24275868
VALVE,CONTROL SOLENOID (W/ BODY & TCM)(IS NOT A CNTRL VALVE BODY ASM W/VALVE BODY,VLVS,SPRINGS. IS A TRNS CNTRL MODULE/TCM W/SOLENOIDS,FILTER PLATE. DOES NOT INCLUDE PASS-THROUGH CNNCTR SEAL.)(INCLUDES 16)(PROGRAMMING REQ BEFORE USE)(INCLUDES TRANS FLUID TEMPERATURE SENSOR))(FOR ALL SRVCABLE CNTRLS COMPONENTS,MUST ORDER EITHER A CNTRL VALVE BODY KIT,OR A SEAL/OVERHAUL KIT,DOES NOT INCLUDE PASS-THROUGH CONNECT SEAL(ILL CALL OUT 10))- Fitting Vehicle Options: L(MH4,MH2)
$1047.50 $664.86
24211326
GASKET,AUTOMATIC TRANSMISSION CASE COVER CENTER(PART OF 1)(*KIT1)- Fitting Vehicle Options: L(MN5)
$13.48 $8.61
274676
RETAINER-EXTRING, M8 SHAFT DIAMETER, 7.1 FREE INSIDE DIAMETER, SAE 1060 STEEL, PLAIN(4TH BAND SERVO PINION RETAINER)- Require Quantity: 02
- Package Quantity: 1
$4.63 $2.96
- 24233212
SOLENOID,4-3 DOWNSHIFT ON/OFF (NORMALY CLOSED)(INCLUDES 136)(PART OF 138)(INCLUDES SEAL)- Fitting Vehicle Options: LT(ME7)
- $38.23 $24.40
$11.10 $7.08
24203912
BOLT,VALVE BODY COVER(M8X1.25X28.0)- Fitting Vehicle Options: L(MN5)
- Require Quantity: 09
- Package Quantity: 1
$7.99 $5.10
8631210
RING,TURBINE SHAFT RETAINER(TURBINE SHAFT TO DRIVE SPROCKET)(4.131)- Fitting Vehicle Options: L(MN5), L(ME7)
$9.53 $6.08
- $321.80 $204.51
- $33.41 $21.31
24200207
BOLT,AUTOMATIC TRANSMISSION CASE COVER(M6X1.0X28.0)- Fitting Vehicle Options: L(MN5)
- Require Quantity: 08
- Package Quantity: 1
$4.46 $2.84
- 19260607
FLANGE,INPUT CARRIER(SEE GROUP 04.000 "INPUT INTERNAL GEAR & FORWARD CLUTCH HUB" FOR DETAILED ILLUSTRATED VIEW)- Fitting Vehicle Options: L(MN5), L(ME7)
24201612
RING,FRONT DIFFERENTIAL CARRIER INTERNAL GEAR WEAR- Fitting Vehicle Options: LF,LR(LE5,LE9,FX2,MN5), L(LAT,ME7,FY1)
24200093
BOLT,AUTOMATIC TRANSMISSION INPUT SPEED SENSOR(M6 X 1.0 X 15.0)(4.329)- Fitting Vehicle Options: L(LAT,LE5)
- Require Quantity: 02
- Package Quantity: 1
$11.36 $7.25
8651649
RETAINER,AUTOMATIC TRANSMISSION NAME PLATE(PUSH ON)(PART OF 51)- Fitting Vehicle Options: L(MN5)
24231142
PUMP,AUTOMATIC TRANSMISSION FLUID(REMANUFACTURED-NOT FOR SALE WHERE IMPORTS ARE RESTRICTED)- Fitting Vehicle Options: L(MN5)
$10.45 $6.68
- $43.16 $27.55
$8.21 $5.24
$7.38 $4.72
$27.96 $17.85
- 24236976
PLATE,2ND CLUTCH(UNIQUE FRICTION MTRL)(IF ORDERING TOGETHER WITH OVERHAUL KIT,TRANS JULIAN DATE PRIOR TO 12DEC 2006 USE 19259234, ON & AFTER 12DEC 2006 USE 24242026)- Fitting Vehicle Options: L(MN5)
- Require Quantity: 03
- Package Quantity: 1
$10.50 $6.70
24210129
LINK,DRIVE(TURBINE SHAFT TO DRIVE SPROCKET)(USE WITH 7/8" WIDE SPROCKET)(USE TOGETHER WITH 24210128,24210130)- Fitting Vehicle Options: L(ME7,MN5)
24240184
SEAL,CONTROL VALVE BODY COVER WIRING CONNECT HOLE(*KIT1)- Fitting Vehicle Options: LR(26)(MH4), LR(26)(LY7,MH2,D70), LG(26)(MH4,D70)
$17.07 $10.90
24229374
CUP,FRONT DIFFERENTIAL DRIVE PINION GEAR BEARING- Fitting Vehicle Options: L(MH4,MH2,D70)
- Require Quantity: 02
- Package Quantity: 1
$12.15 $7.76
- 24235005
PLATE,CONTROL VALVE BODY SPACER(INCLUDES GASKETS)(TRANS BUILT ON 01-22-08 & PRIOR)(FOR 2ND DESIGN SEE 24245914)- Fitting Vehicle Options: L(MN5)(SERV BULLETIN# 08-07-30-034 APPLIES TO THIS PART #.PER GM SERV POLICIES & PROC,FAILURE TO FOLLOW THE BULLETIN MAY RES IN THE REJ OF A WARR CLAIM)(1ST DES)
$10.14 $6.47
104918
BALL,1/4" DIAMETER,CHROME STEEL(CONTROL VALVE BODY BALL CHECK(POSITION 2,3,4,5,6))- Require Quantity: 07
- Package Quantity: 10
$0.07 $0.04
24215951
CARRIER,FRONT DIFFERENTIAL(3.05 RATIO)(SEE GROUP 04.000 "FINAL DRIVE & DIFFERENTIAL" FOR DETAILED ILLUSTRATED VIEW)- Fitting Vehicle Options: LT(LAT,ME7,FY1)
$12.14 $7.75
- 24217590
LINK,DRIVE(TURBINE SHAFT TO DRIVE SPROCKET)(USE WITH 5/8" WIDE SPROCKET)- Fitting Vehicle Options: L(MN5)
$151.78 $96.90
$12.21 $7.80
24214159
BEARING,INPUT CARRIER THRUST(66MM O.D. X 48.5MM I.D)- Fitting Vehicle Options: L(MN5), L(ME7)
- Require Quantity: 02
- Package Quantity: 1
$31.40 $20.01
$32.28 $20.60
24249846
SWITCH,AUTOMATIC TRANSMISSION FLUID PRESSURE MANUAL VALVE POSITION(FAILURE TO FOLLOW GM SERVICE BULLETIN 09-07-30-008 MAY RESULT IN THE REJECTION OF A WARRANTY CLAIM)- Fitting Vehicle Options: L(LAT,ME7,FY1)
$69.23 $44.20
24227888
GASKET KIT,AUTOMATIC TRANSMISSION CASE COVER(INCLUDES 28,49)(INCLUDES SEALS)- Fitting Vehicle Options: L(MN5)
$125.50 $80.07
