2023 Cadillac XT6 Transaxle Parts
Currently shopping for
2023 Cadillac XT6
Change VehicleCategories Close X
Currently selected
Engine
Other Categories
A/C & Heating
Air & Fuel Delivery
Belts & Cooling
Body & Hardware
Brakes
Charging & Starting
Driveline & Axles
Electrical
Emission Control & Exhaust
Headlights & Lighting
Interior & Exterior Trim
Maintenance & Lubrication
Steering
Suspension
Transmission
Parts Questions
2 diagrams found for the vehicle you selected.Select your vehicle options to narrow down results.
- 1.Engine / Transaxle - Transaxle Parts (2.0 L Turbo)
- 2.Engine / Transaxle - Transaxle Parts (3.6 L)
Sort by:
Ref No.
Ref No.
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
Part Description
- 24264987
SEAL,AUTOMATIC TRANSMISSION CASE (O RING)(PART OF 10)(REAR ACCUMULATOR TO CASE)(QTY 2 REQ PER TRANS)(*KIT2)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9)
- Require Quantity: 02
- Package Quantity: 1
$1.88 $1.20
24267681
RING,1-2-3-4-5-6 CLUTCH BACKING PLATE RETAINER(*KIT1)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9), NW(26)(LGX,M3W,FWD,FXC), NW,NX(26)(LGX,M3W,FXC,F48)
$0.26 $0.17
24286803
PLATE,1-2-3-4-5-6 CLUTCH (WAVED)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,FWD,KL9), NV(26)(LSY,M3G,FHB,F48,KL9), NW(26)(LGX,M3W,FWD,FXC), NW,NX(26)(LGX,M3W,FXC,F48)
$3.72 $2.37
- 11547422
BOLT,CONTROL VALVE SOLENOID BODY- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9), NW(26)(LGX,M3W,FWD,FXC), NW,NX(26)(LGX,M3W,FXC,F48)
$3.98 $2.54
8654382
PLUG,AUTOMATIC TRANSMISSION FLUID PRESSURE TEST HOLE(1/8-27)(NPFT HEXAGON HEAD)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9), NW(26)(LGX,M3W,FWD,FXC), NW,NX(26)(LGX,M3W,FXC,F48)
$7.20 $4.74
24240663
SEAL,DRIVE LINK LUBRICANT FLUID(PART OF 60)(13.20MM OUTSIDE DIAMETER)- Fitting Vehicle Options: NV(26)(LSY,M3G)
$2.26 $1.47
24268389
SEAL,AUTOMATIC TRANSMISSION FLUID PUMP(6-PORTION TRANSFER)(*KIT1)- Fitting Vehicle Options: NV(26)
$3.52 $2.25
- 24044529
CASE,AUTOMATIC TRANSMISSION(ORDER TOGETHER WITH 24285407 SHAFT ASM-MANUAL SHIFT ON APPLICATIONS W/ MANUAL PARKING RELEASE CABLE. SEE ESI)(INCLUDES 54-58,66,75)(W/O EXTERNAL MANUAL PARKING RELEASE LEVER)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,KL9)
$428.43 $272.35
- 24293117
CONVERTER,TORQUE- Fitting Vehicle Options: NW(26)(LGX,M3W,FWD,FXC), NW,NX(26)(LGX,M3W,FXC,F48)
$339.71 $217.99
11588713
BOLT,AUTOMATIC TRANSMISSION INPUT SPEED SENSOR(M6X1X25)(8.900)- Fitting Vehicle Options: NV(26)(LSY), NW,NX(26)(LGX)
$6.19 $4.80
24267678
PLATE,1-2-3-4-5-6 CLUTCH- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9), NW,NX(26)(LGX,M3W,FXC,F48), NW(26)(LGX,M3W,FWD,FXC)
- Require Quantity: 02
- Package Quantity: 1
$2.38 $1.52
- 24267848
GASKET,TORQUE CONVERTER HOUSING(*KIT1)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9)
$19.46 $12.42
- 24050076
PISTON,1-2-3-4-5-6 CLUTCH(INCLUDES 600)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB), NW,NX(26)(LGX,M3W,FXC,F48), NW(26)(LGX,M3W,FWD,FXC)
$20.70 $13.22
- 11547175
BOLT,VALVE BODY(M5X0.8X94)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,FWD,KL9), NV(26)(LSY,M3G,FHB,F48,KL9), NW(26)(LGX,M3W,FWD,FXC), NW,NX(26)(LGX,M3W,FXC,F48)
- Require Quantity: 08
- Package Quantity: 1
$0.60 $0.38
- 24285336
SEAL,AUTOMATIC TRANSMISSION FLUID TEMPERATURE SENSOR (O RING)(*KIT1)- Fitting Vehicle Options: NV(26)(LSY,M3G)
$2.24 $1.43
104918
VALVE,CONTROL VALVE BODY BALL CHECK(.25 DIAMETER)(8.899)- Fitting Vehicle Options: NV(26), NW,NX(26)
$0.07 $0.04
24044493
CAP,TRANS FLUID FILLER(W/VENT)(INCLUDES 77)- Fitting Vehicle Options: NV(26)(M3G), NW,NX(26)(M3W)
$14.30 $9.13
24237428
RING,3-5-REV & 4-5-6 CLUTCH FLUID SEAL(PART OF 64)(4.105)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,FWD,KL9), NV(26)(LSY,M3G,FHB,F48,KL9)
$1.60 $1.02
- 24298740
BAFFLE,FRONT DIFFERENTIAL CARRIER(BOLTS TO CASE ASSEMBLY SIDE)- Fitting Vehicle Options: NW(26)(LGX,M3W,FWD,FXC), NT,NW,NX(26)(LGX,M3W,FXC,F48)
$5.88 $3.75
- $2.12 $1.36
- 24047196
HOUSING,1-REV & 1-2-3-4-5-6 CLUTCH PISTON- Fitting Vehicle Options: NW(26)(LGX,M3W,FXC,FWD), NW,NX(26)(LGX,M3W,FXC,F48)
$225.25 $143.19
- $48.64 $31.06
24280145
RING,1-2-3-4-5-6 CLUTCH SPRING RETAINER(4.164)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,FWD,KL9), NV(26)(LSY,M3G,FHB,F48,KL9), NW(26)(LGX,M3W,FWD,FXC), NW,NX(26)(LGX,M3W,FXC,F48)
$0.37 $0.24
- 11547377
BOLT,VALVE BODY(M5X0.8X55)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9)
- Require Quantity: 05
- Package Quantity: 1
$0.17 $0.10
24277333
SEAL,1-2-3-4-5-6 CLUTCH PISTON INNER- Fitting Vehicle Options: NV(26)(LSY,M3G), NW,NX(26)(LGX,M3W)
$1.15 $0.73
- 24288671
SEAL,1-2-3-4 LOW & REV CLUTCH FLUID PASSAGE(KIT)(*KIT1,KIT2)- Fitting Vehicle Options: NV(26)(LSY,M3G)
$7.70 $4.92
- 24054202
BODY,CONTROL VALVE SOLENOID(INCLUDES 31)(KIT)(ETRS)(W/OIL LEVEL CONTROL)- Fitting Vehicle Options: NV(26)(LSY,M3G)(TSB# 23-NA-135 APPLIES TO THIS PART. PER GM SERVICE POLICIES & PROCEDURES, FAILURE TO FOLLOW THE TSB MAY RESULT IN REJECTION OF A WARRANTY CLAIM)
- Replaced By: 24065459
$899.27 $590.09
- 24288114
SEAL,ACCUMULATOR BYPASS VALVE(OVERHAUL)( PART OF 10)(ACCUMULATOR SOLENOID BODY-TO-ACCUMULATOR BODY)(*KIT1,KIT2)- Fitting Vehicle Options: NV(26)(LSY,M3G)
$0.93 $0.59
- 24240662
SEAL,DRIVE LINK LUBRICANT FLUID(12.28MM OUTSIDE DIAMETER)- Fitting Vehicle Options: NF,NH,NV(26)(LSY,M3G,FHB,KL9)
$0.96 $0.62
- 24298739
BAFFLE,FRONT DIFFERENTIAL CARRIER(CASE SIDE)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9)
$9.93 $6.34
- 24044721
HARNESS,AUTOMATIC TRANSMISSION WIRING(W/OIL LEVEL CONTROL)(TSB# 23-NAME-135 APPLIES TO THIS PART.)(PART OF 8)(SOLENOID)(ETRS)(PER GM SERVICE POLICIES & PROCEDURES, FAILURE TO FOLLOW THE TSB MAY RESULT IN THE REJECTION OF A WARRANTY CLAIM.)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,FWD,KL9), NV(26)(LSY,M3G,FHB,F48,KL9)
$143.14 $91.38
- 24297282
SEAL,1-2-3-4-5-6 CLUTCH PISTON(PART OF 592)- Fitting Vehicle Options: NV(26)(LSY,M3G), NW,NX(26)(LGX,M3W)
$1.47 $0.94
- 24045815
VALVE,AUTOMATIC TRANSMISSION FLUID LEVEL CONTROL- Fitting Vehicle Options: NF,NH,NV(26)(LSY,M3G,FHB,F48,KL9), NF,NH,NV(26)(LSY,M3G,FHB,FWD,KL9), NW(26)(LGX,M3W,FWD,FXC), NT,NW,NX(26)(LGX,M3W,FXC,F48)
- Replaced By: 24058739
$18.82 $12.02
- 11547173
BOLT,VALVE BODY(M5X0.8X65)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9), NW,NX(26)(LGX,M3W,FXC,F48), NW(26)(LGX,M3W,FWD,FXC)
- Require Quantity: 03
- Package Quantity: 1
$7.21 $4.60
- 24241923
BOLT,FRONT DIFFERENTIAL CARRIER BAFFLE(M6X1.0X18.5)- Fitting Vehicle Options: NV(26), NW,NX(26)
- Require Quantity: 02
- Package Quantity: 1
$10.66 $6.80
- 24280824
SEAL,BODY SIDE WIRING HARNESS OPENING(CROSS SECTION:3.3MM WIDE X 7.21MM HIGH)(PASS-THROUGH CONNECTOR)(*KIT1)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9)
$3.63 $2.32
24267680
PLATE,1-2-3-4-5-6 CLUTCH BACKING- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,FWD,KL9), NV(26)(LSY,M3G,FHB,F48,KL9), NW(26)(LGX,M3W,FWD,FXC), NW,NX(26)(LGX,M3W,FXC,F48)
$4.90 $3.12
24290714
PLATE,1-2-3-4-5-6 CLUTCH (W/FRICTION MATERIAL)(THIS P/N IS NOT A KIT CONTAINING A FULL SET FBR CLUTCH PLTS. ORDER THE CORRECT QTY OF THIS PART NEEDED FOR VEHICLE SERVICE.)- Fitting Vehicle Options: NV(26)(LSY,M3G), NW,NX(26)(LGX,M3W)
- Require Quantity: 02
- Package Quantity: 1
$1.67 $1.06
- 24289001
SCOOP,DRIVE LINK LUBRICANT(INCLUDES 61)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,FWD,KL9), NV(26)(LSY,M3G,FHB,F48,KL9)
$12.15 $7.75
- 24045606
ACCUMULATOR,AUTOMATIC TRANSMISSION AUXILIARY FLUID(INCLUDES 27,28,33-35)(KIT)(W/ACCUMULATOR SOLENOID COVER)(MATING CONNECT USE 19355451)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,KL9), NW,NX(26)(LGX,M3W,FXC,F48), NW(26)(LGX,M3W,FWD,FXC)
$361.22 $229.62
- 24285074
SEAL,AUTOMATIC TRANSMISSION INPUT SPEED SENSOR (O RING)(PART OF 70)(*KIT3)- Fitting Vehicle Options: NV(26)(LSY,M3G)
$2.10 $1.34
- 24271624
SEAL,ACCUMULATOR BYPASS VALVE(PART OF 10)(FRONT ACCUMULATOR-TO-CASE)(*KIT1,KIT2)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9), NW(26)(LGX,M3W,FWD,FXC), NW,NX(26)(LGX,M3W,FXC,F48)
$1.53 $0.97
24282417
SPRING,1-2-3-4-5-6 CLUTCH PISTON RETURN- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9), NW(26)(LGX,M3W,FWD,FXC), NW,NX(26)(LGX,M3W,FXC,F48)
$8.70 $5.54
- 24298738
BAFFLE,FRONT DIFFERENTIAL CARRIER(PLASTIC)(PART OF TORQUE CONVERTER DIFFERENTIAL HOUSING ASM)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,FWD,KL9), NV(26)(LSY,M3G,FHB,F48,KL9)
$9.78 $6.25
- 24054204
BODY KIT,CONTROL VALVE(INCLUDES 50)(KIT)(ETRS)(W/OIL LEVEL CONTROL)(TSB# 23-NAME-135 APPLIES TO THIS PART. PER GM SERVICE POLICIES & PROCEDURES, FAILURE TO FOLLOW TSB MAY RESULT IN THE REJECTION OF A WARRANTY CLAIM)- Fitting Vehicle Options: NW(26)(LGX,M3W,FWD,FXC), NW,NX(26)(LGX,M3W,FXC,F48)
$69.35 $44.28
24249634
SUPPORT,INPUT SHAFT(PART OF 64)(GENERATOR 2 DESIGN)- Fitting Vehicle Options: NV(26)(LSY,M3G,FHB,F48,KL9), NV(26)(LSY,M3G,FHB,FWD,KL9), NW,NX(26)(LGX,M3W,FXC,F48), NW(26)(LGX,M3W,FWD,FXC)
$43.01 $27.45
